China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine

รายละเอียดสินค้า

สถานที่กำเนิด: จีน

ชื่อแบรนด์: Beyde

ได้รับการรับรอง: CE

หมายเลขรุ่น: 500/1+6

เงื่อนไขการชําระเงินและการจัดส่ง

จำนวนสั่งซื้อขั้นต่ำ: 1 ชุด

รายละเอียดการบรรจุ: บรรจุภัณฑ์เพื่อความปลอดภัย

เวลาการส่งมอบ: 90 วัน

เงื่อนไขการชำระเงิน: l/c, d/a, d/p, t/t

สามารถในการผลิต: 200 ชุด/ปี

หา ราคา ที่ ดี ที่สุด
รายละเอียดสินค้า
เน้น:

500mm tubular stranding machine

,

big bearing tubular stranding machine

,

China manufacture tubular stranding machine

การใช้งาน:
การตึงเครียด
สี:
ตามความต้องการของลูกค้า
ชื่อ:
เครื่องพันท่อ
แอปพลิเคชัน:
เหล็ก, อลูมิเนียม, ลวดเหล็ก stranding
วัสดุลวด:
เหล็ก,ทองแดง
กระสวยจ่ายเงินกลาง:
PN400-PN630
ขนาดกระสวยรับ:
ภงด.800-ภงด.1600
เส้นผ่านศูนย์กลางลวดเปลือยสูงสุด:
4 มม.
การรับประกัน:
12 เดือน
การใช้งาน:
การตึงเครียด
สี:
ตามความต้องการของลูกค้า
ชื่อ:
เครื่องพันท่อ
แอปพลิเคชัน:
เหล็ก, อลูมิเนียม, ลวดเหล็ก stranding
วัสดุลวด:
เหล็ก,ทองแดง
กระสวยจ่ายเงินกลาง:
PN400-PN630
ขนาดกระสวยรับ:
ภงด.800-ภงด.1600
เส้นผ่านศูนย์กลางลวดเปลือยสูงสุด:
4 มม.
การรับประกัน:
12 เดือน
คําอธิบายสินค้า



China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine



This high speed machines mainly used for stranding copper wire,aluminum wire, steel wire,ACSR and wire rope.Accompanied with taping head,it can used for insulation cores and some control cable stranding process.

Application:
This high speed machines mainly used for stranding copper wire,aluminum wire, steel wire,ACSR and wire rope.Accompanied with taping head,it can used for insulation cores and some control cable stranding process.
Component:
Central pay-off. cage host,taping device (optional),capstan,take-up and traverse device,and electric control system.



Model 400 500 630
Inlet wire Dia.(mm) Conductor 1.5-3.5 1.8-4.0 2.0-5.0
Steel 1.0-2.5 1.5-3.0 1.8-4.0
Cores 1.2-3.5 1.5-5.0
Frame rotation speed(r/min) 700 600 400
Stranding Pitch(mm) 41-312 44-334
Linear Speed(m/min) 27-205.3 22-166.85 14-108.9
Capstan Dia.(mm) 800+1000 1000+1200 1000+1250
Size of tak-up bobbin PN1250 PN1600 PN1600



China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine 0

China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine 1

FAQ
1.Q: Where is your factory located? A: Our factory is located in HEJIAN CITY, HEBEI PROVINCE, CHINA,
we are near Beijing, Tianjin and Shijiazhuang air port, and CANGZHOU WEST high-speed railway station.
2.Q: What is the advantage about your company? A: Our company has skilled technical engineer and workers and professional production line.
3.Q: Why should l choose your products? A: We are direct manufacturer, we can ensure the stable product quality and provide in time service.
4.Q: The logo and the color can be customized? A: Yes
5.Q:What's your near sea loading port: Tianjin port
